MeteoSense - Barometric Pressure Sensor BPS-500
• Three fully integrated pressure sensing elements operate in parallel. Their data is internally processed, cross-validated and averaged.
• Supply Voltage: 5 ... 45 VDC
• Power Consumption (at 12 V): < 1mA (standby 40 μA)
• Range: 600 ... 1100 hPa
• Accuracy: ±0.2 hPa (600 ... 1100 hPa, –40 ... 85 °C)
• Resolution: 1/64 hPa ≈ 0.0156 hPa
• Output Voltage: 0 ... 2.5 or 0 ... 5 VDC
• Long-Term Drift: ±0.05 ... 0.06 hPa
• Dimensions: 64 x 92 mm, 64 x 62 mm (with rail mount)
• Optional as standard version: Without DIN rail mount (On request)
