Ammonit M83572 Modul
• Module for 10 Ports / RS485 2-wire / Configurable UOUT
• Stabilised and ripple-free voltage output individually configurable
• 10 individually configurable ports:
• Pull-up resistor R1
• Pull-up resistor R2
• Pull-down resistor R3
• One stabilised and ripple-free output with active current limit (110 mA)
• One configurable bus-termination resistor (120 Ω) for two-wire RS485 bus setup (half duplex)
• Each terminal comprises overvoltage protection
• Supply voltage: UOUT + 4 ... 32 VDC
• Dimensions: 22.5 x 110 x 115 mm
• Operating temperature: -40 ... +75 °C
Datenblatt
