• 3.1157.10.000
• 0...5V output, set 800...1060 hPa
• 300...1100 hPa scalable
• Long-term stability ±0.3 hPa/year
• Accuracy ±1.0 hPa (unheated)
• Accuracy ±0.25 hPa (heated)

ZXTM Horizontal Wind Profiler
• 17 horizontal ranges with configurable dwell times
• Wind characteristics: wind speed, shear, veer, wind yaw misalignment, turbulence, rotor equivalent wind speed (REWS), windflow complexity
• Wind speed range: < 0.5-45 m/s (wind loading survivability up to 70 m/s)
• Accuracy: Direction - 0.5°, Speed - 0.1 m/s
• 50 Hz /20 ms measurements (50 measurements per second)
• Measurement range: 10m - 550m
• 3 year warranty included
• no factory maintenance or calibration required  in 3 year service period

The device can measure the Isc and Voc values from up to two solar PV panels simultaneously
• Compatibility:
    Analog output: all Kintech Engineering data loggers
    Digital output: Orbit 360 Premium
 • Inputs:
    Isc range: 0 ... 20 A, 0 ... 30 A
    Isc accuracy: 0.1 %
    Voc range: 0 ... 60 V
    Voc Accuracy: 0.1 %
 • Outputs:
    Analog range: 0 ... 5 V
    Analog transfer function: Check “How to configure“ table
    Digital*: RS485
    Digital protocol: Modbus RTU

• 4.3352.10.400 - unbeheizt
• Class A compliant according to IEC 61400-12-1 & 61400-12-1 Ed.2
• W/o heating
• Measurement Range: 0.3...75 m/s
• Outputs: RS485 / ASCII / MODBUS
• Option for connecting a bus-compatible wind vanes and anemometers in parallel (daisy chain)
• Measures next to wind speed also:
   Air pressure: 300 ... 1100 hPa (Accuracy: ±1 hPa @ 20 °C)
   Indication: Measuring range: -89.9 ... +89.9° (Accuracy: ±1 °)
   Vibration: Measuring range: 0 ... 50 Hz (Accuracy: ±0.4 Hz)
   Acceleration: Measuring range: ±8 g (Accuracy: ±30 mg)

• 4.3351.10.000 - unheated
• Frequency output (1082 Hz at 50 m/s)
• Class A compliance in accordance to IEC 61400-50-1 (latest version)
• Supply 3.3 ... 42 V DC
• Measurement Range: 0.3...75 m/s
• Accuracy: 1% of value or <0.2 m/s (0.3...50m/s)
• Linearity: r>0.99999 (4...20 m/s)
• W/o heating

• 4.3151.10.001​
• TMR-Sensor (Tunnel Magneto Resistance)
• Measurement range: 0...360°
• Digital output protocoll: 16 bit serial synchronous
• Digital output: 10 bit Gray Code
• Without north gap
• Accuracy: 0.75°
• Resolution: 0.35°
• W/o heating

• Certified verification of Remote Sensing Device (some may call it "calibration")
• Carried out in accordance to the IEC 61400-50-1 and IEC 61400-50-2, accredited as per ISO 17025
• Conducted at a 200m reference mast
• Procedure warrants lowest uncertainties, highest accuracy, and compliance in line with IEC, FGW and IEA

• ISO 9060: Secondary Standard
• Heating, tilt sensor, internal ventilation
• Measurement range: -400 to 4000 W/m²
• Spectral range: 285 to 3000 nm
• Incl. calibration sheet (traceable to WRR)
• Power consumption (dew and frost mitigation mode): < 3 W

ZXTM Horizontal Wind Profiler - Monthly rental service
• 17 horizontal ranges with configurable dwell times
• Wind characteristics: wind speed, shear, veer, wind yaw misalignment, turbulence, rotor equivalent wind speed (REWS), windflow complexity
• Wind speed range: < 0.5-45 m/s (wind loading survivability up to 70 m/s)
• Accuracy: Direction - 0.5°, Speed - 0.1 m/s
• 50 Hz /20 ms measurements (50 measurements per second)
• Measurement range: 10m - 550m
• 3 year warranty included
• no factory maintenance or calibration required  in 3 year service period

• Once powered up, the measurement automatically starts
• Calibration certificate (standards traceable to U.K.A.S accreditation service)
• 16x analogue single-ended or 8 differential Analog Inputs, 10x pulse counters, 8x digital IN/OUT (configurable), 4x analogue voltage (switched excitation mode or switched regulated voltage supply), 2x switched 12V
• RS485/232, CS I/O PORT to CSI peripherals, USB, Ethernet (LAN) port, Wi-Fi (optional module)
• 4 Mbytes battery-backed SRAM + 72 MB flash memory, expandable to 8 GB
• Surge, Electrostatic Discharge and Lightning Protection for all critical Inputs and Outputs
• Power in 9.6V to 36VDC
• Stainless steel type-D connectors and gold plating improvements on RJ45s
• Standard operating range of -40° to +70°C (optionally extended: -55° to +85°C)

• Customized plans for individual measurement systems
• Power lines
• Fuse plan
• Signal lines

• 4.3151.00.173
• TMR-Sensor (Tunnel Magneto Resistance)
• Measurement range: 0...360°
• Electrical output 0 ... 5 V
• Resolution analogue = 10 bit
• Without north gap
• Accuracy: 0.25% (1°)
• Resolution: 0.35°
• With heating (24V AC / DC, 25W)

• 4.3151.10.001​
• TMR-Sensor (Tunnel Magneto Resistance)
• Measurement range: 0...360°
• Digital output protocoll: 16 bit serial synchronous
• Digital output: 10 bit Gray Code
• Without north gap
• Accuracy: 0.75°
• Resolution: 0.35°
• W/o heating

• Compliant to recommendations of FGW TR6, IEC and MEASNET
• Incl. calibration certificate
• Calibration standards traceable to U.K.A.S and/or NIST/NVLAP accreditation service (through ilac-MRA)
• Executed by a third party accredited calibration laboratory (DIN EN ISO/ISO 17025)

• Collects and processes sensor measurement data using advanced algorithms
• Stores observations, device information and maintenance history
• Operating conditions: -40°C... +85°C, 0 ... 100 %RH
• Operating voltage: 8-32V DC (max. 10A)

• 500 ... 1100 hPa (optional range settings)
• Long-term stability ±0.1 hPa/year
• Accuracy ±0.15 hPa at +20 °C
• Traceable NIST calibration incl. certificate

• Compatible with Orbit 360 Premium Data Logger
• Adds 6 more frequency channels to the Orbit 360 Premium
• Each channel can be configured individually
• Excellent noise and interface protectionT
• Resolution: 16 bits
• IEC-61400.12.1 approved sampling rate of 1Hz

Accredited, Bankable Installation Report
​• Conformity check with IEC, MEASNET and FGW
• "Certificate of Bankability" compliant to:
   • ISO / IEC 61400-50-1 and IEC 61400-50-2
   • MEASNET
   • FGW TR6
