Herzlich Willkommen in ProfEC's One Stop Wind Shop!

ZXTM Horizontal Wind Profiler
• 17 horizontal ranges with configurable dwell times
• Wind characteristics: wind speed, shear, veer, wind yaw misalignment, turbulence, rotor equivalent wind speed (REWS), windflow complexity
• Wind speed range: < 0.5-45 m/s (wind loading survivability up to 70 m/s)
• Accuracy: Direction - 0.5°, Speed - 0.1 m/s
• 50 Hz /20 ms measurements (50 measurements per second)
• Measurement range: 10m - 550m
• 3 year warranty included
• no factory maintenance or calibration required  in 3 year service period

• 4.3351.10.000 - unheated
• Frequency output (1082 Hz at 50 m/s)
• Class A compliance in accordance to IEC 61400-50-1 (latest version)
• Supply 3.3 ... 42 V DC
• Measurement Range: 0.3...75 m/s
• Accuracy: 1% of value or <0.2 m/s (0.3...50m/s)
• Linearity: r>0.99999 (4...20 m/s)
• W/o heating

WindCube Winter Kit
• Leosphere accessory for WindCube v2.1
• Tilted surface for low snow retention
• Active heating element with 2 selectable power modes (90 or 120W)
• Easy installation
• Tested in harsh weather conditions with snow and ice at -20°C
• Suitable for remote and hard-to-reach places
• Input power supply: 24.5 - 27 VDC

• Once powered up, the measurement automatically starts
• Calibration certificate (standards traceable to U.K.A.S accreditation service)
• 16x analogue single-ended or 8 differential Analog Inputs, 10x pulse counters, 8x digital IN/OUT (configurable), 4x analogue voltage (switched excitation mode or switched regulated voltage supply), 2x switched 12V
• RS485/232, CS I/O PORT to CSI peripherals, USB, Ethernet (LAN) port, Wi-Fi (optional module)
• 4 Mbytes battery-backed SRAM + 72 MB flash memory, expandable to 8 GB
• Surge, Electrostatic Discharge and Lightning Protection for all critical Inputs and Outputs
• Power in 9.6V to 36VDC
• Stainless steel type-D connectors and gold plating improvements on RJ45s
• Standard operating range of -40° to +70°C (optionally extended: -55° to +85°C)

• Certified verification of Remote Sensing Device (some may call it "calibration")
• Carried out in accordance to the IEC 61400-50-1 and IEC 61400-50-2, accredited as per ISO 17025
• Conducted at a 200m reference mast
• Procedure warrants lowest uncertainties, highest accuracy, and compliance in line with IEC, FGW and IEA

ZXTM Horizontal Wind Profiler - Monthly rental service
• 17 horizontal ranges with configurable dwell times
• Wind characteristics: wind speed, shear, veer, wind yaw misalignment, turbulence, rotor equivalent wind speed (REWS), windflow complexity
• Wind speed range: < 0.5-45 m/s (wind loading survivability up to 70 m/s)
• Accuracy: Direction - 0.5°, Speed - 0.1 m/s
• 50 Hz /20 ms measurements (50 measurements per second)
• Measurement range: 10m - 550m
• 3 year warranty included
• no factory maintenance or calibration required  in 3 year service period

• 4.3151.10.001​
• TMR-Sensor (Tunnel Magneto Resistance)
• Measurement range: 0...360°
• Digital output protocoll: 16 bit serial synchronous
• Digital output: 10 bit Gray Code
• Without north gap
• Accuracy: 0.75°
• Resolution: 0.35°
• W/o heating

For Thies and Vector Instruments (Windspeed Ltd.) anemometer:
• Repair (costs are sensor specific and depend on malfunction found)
• Certificate
• Authorization seal
Scope & costs for repair depend on the individual sensor defects & conditions. A sensor specific offer will be made based upon inspection.

• 12x pulse counters IN
• 7x analog voltage IN
• Requires external 12VDC power supply
• 7x configurable 'Flex' Channels (Analog or Counter) with optional signal conditioning modules (P-SCMs)
• 512 MB SD Card, non-volatile flash memory
• Resolution: 16 bit ad
• Accuracy: 0.04 % of full scale
• LCD with 16 button keypad
• 2x RS485 serial communication on wiring panel

• Module for 10 Ports / RS485 2-wire / Configurable UOUT
• Stabilised and ripple-free voltage output individually configurable
• 10 individually configurable ports
• One stabilised and ripple-free output with active current limit (110 mA)
• One configurable bus-termination resistor (120 Ω) for two-wire RS485 bus setup (half duplex)
• Each terminal comprises overvoltage protection

• NPort 5150 Serial Device Servers
• Designed to make serial devices network-ready in an instant
• 1x 10/100 Base T(X) Port (RJ45 connector)
• Real COM and TTY drivers for Windows, Linux and macOS
• Configurable by Telnet, web browser, or Windows utility
• Small size for easy installation
• Operating/Storage temperature: -40°C to 75°C
• 5 years warranty

• Module for 10 Ports / RS485 2-wire / Configurable UOUT
• Stabilised and ripple-free voltage output individually configurable
• 10 individually configurable ports
• One stabilised and ripple-free output with active current limit (110 mA)
• One configurable bus-termination resistor (120 Ω) for two-wire RS485 bus setup (half duplex)
• Each terminal comprises overvoltage protection

• Lockable
• Enables save and comfortable work at the control cabinet / shelter box enclosure
• Protecting against unauthorised climbing and thievery

​• Plastic Enclosure
• Complete internal wiring, clamps, etc. ready for plug&play
• Includes terminal connectors and internal wiring to connect sensors, modem, data logger, charge controller and power supply
• Incl. mounting of other, ordered equipment from One Stop Wind Shop like barometer, modem, data logger, charge controller, battery, etc.
• Individual ground / earthing conductor lug for sensor mounting plate and shields (needed for galvanic separation of measurement system and cabinet from mast structure)

Barobox
• In the barometer box, several barometer types can be located: Setra (278 / 276) , Vaisala (PTB110), Amonit (AB 60 / AB 00) etc. the box is vented by a membrane inlet to enable pressure equalization inside
• Length x width x height: 80 x 80 x 51 mm
• IP protection class: IP 54
• Operating range: -25 to 40 deg C
• Outdoor Protection

• Vertical pipe mounting set: pipe min. diameter 40 mm, max. diameter 150 mm
• Stainless steel

• Compliant to recommendations of FGW TR6, IEC and MEASNET
• Incl. calibration certificate
• Calibration standards traceable to DAkkS (ilac-MRA) accreditation service

Feeds measurement system with high and particular heating needs for sensors
• 1x solar charge controller and regulator (30-50 A)
• ~205 Ah battery capacity or more
• Charging power source: solar panels (incl. slope-adjustable mounting rack support). Combination with small wind turbine (incl. mounting tube for mast mounting) or  H2 fuel cell or methanol Efoy fuel cell etc. possible
​• 1x shelter box approx. 800 x 600, incl. mast support
